Keor FLEX - Three-Phase Modular UPS | Up to 1.2 MW
As data centers expand to meet growing demands from cloud computing, AI workloads, and colocation services, the need for energy-efficient and scalable power solutions has never been greater. Keor FLEX is a high-efficiency modular uninterruptible power supply (UPS) designed for high-density data centers, featuring a modular, hot-swappable architecture that enables seamless growth with zero downtime, ensuring continuity of services for mission-critical operations. Delivering market-leading 98.4% efficiency in double conversion mode, Keor FLEX reduces energy consumption, cooling costs, and Total Cost of Ownership (TCO). Its scalable design—supporting up to 1.2 MW in a single frame and expandable to 4.8 MW—makes it the ideal solution for colocation, hyperscale, AI, edge computing, and smart-grid ready installations.
Key Benefits of Keor FLEX High-Power Modular UPS
Unmatched Efficiency
Achieves up to 98.4% in VFI mode and 99% in ECO mode using Silicon Carbide (SiC) technology, minimizing energy losses and OPEX while supporting sustainability.
Zero Downtime Scalability
True modular architecture with hot-swappable power and bypass modules enables pay-as-you-grow scalability and zero-downtime maintenance.
Maximized Power Density for Constrained Space
1.2 MW in just 2.8 m² — maximizing white space utilization.
Thermal Efficiency for Data Center Environments
Keor FLEX incorporates advanced Silicon Carbide (SiC) technology to minimize internal heat generation. This design enhances Power Usage Effectiveness (PUE) by reducing the cooling load, leading to lower energy consumption and improved overall efficiency in data center operations.
Turn Your UPS into a Smart Energy Asset
Supports peak shaving, fast frequency response, and renewable energy integration, with seamless BMS compatibility for energy optimization.
Resilient Design for Maximum Uptime
Redundant modular design with a fault-tolerant busbar ensures continuous operation, while front access and hot-swappable components cut maintenance time to under 5 minutes.
Real-Time Diagnostics at Your Fingertips
10-inch touchscreen and multi-colored LED status bar provide real-time insights, predictive diagnostics, and intuitive system control.
Right-Sized Power with Future Growth in Mind
Delivers up to 1.2 MW per UPS frame using 12 x 100 kW modules, allowing scalable expansion without disruption.
Flexible Load Sharing Across Systems
Supports up to 4 parallel units for a total of 4.8 MW, enabling N+1 or 2N redundancy for mission-critical reliability.
Technical Benefits for Keor FLEX High-Power Modular UPS
Feature | Specifications |
Power Capacity | Scalable from 100 kW to 1.2 MW per system; up to 4.8 MW in parallel, PF=1 |
Efficiency | Up to 98.4% (double conversion); 99% (ECO mode) |
Input Voltage Range | 400 V ±20% (320–480 V); 50/60 Hz |
Battery Compatibility | VRLA, Li-Ion, TPPL; wide DC range 420–680 V – wide range supports diverse battery chemistries and future scalability |
Battery Charging Capacity | Maximum 20 kW per module |
Cooling and Layout | Front-top air ventilation; top/bottom cable or busbar entry |
Protection | Internal backfeed, trapped key bypass, Icw limitation up to 100 kA |
Dimensions (W x H x D) | 2250 × 2100 × 1260 mm (UPS cabinet, full configuration) |
Certifications | IEC 62040-1/-2/-3 /-4 compliant, IEC 62443-4-2, CE marked |




Contact us to discuss the total cost of ownership (TCO)
Keor FLEX sets a new benchmark in data center power infrastructure, delivering unmatched efficiency, scalability, and resilience. Hot-swappable modularity, advanced monitoring, and smart-grid readiness ensure future-proof performance for colocation, hyperscale, and AI-driven facilities.
