Name: Sounder - IP41 - IK04 - 70 dB - 12/24/48 V - white
SKU: 041507

Sounder - IP41 - IK04 - 70 dB - 12/24/48 V - white

Mosaic LEGRAND

Sounder - IP41 - IK04 - 70 dB - 12/24/48 V - white

REF. 041507 EAN. 3245060415075

Compare You can only compare 4 products, you must remove 1 to add this one

Sounders, sounder beacons, bells, electromagnetic door holder and safety electrical power supplies
Sounders - Conform to EN 54 - 3 standard and CE CPR approved - IP 41 - IK 04 - Mosaic device - 2 modules - Sound level : 70 dB at 2 meters - NF S 32 - 001 sound - Voltage range : 10 - 42 V - Average consumption : 12 V DC 5 mA - 24 V DC 9 mA

Built-in depth	30 mm
degree of impact strength (IK)	IK04
Operating / setting temperature	-10-+55 °C
Storage temperature	0-+55 °C
Halogen free	Yes
Connection type	Screwed terminal
Fitted with rainproof plate protection	No
With complemantary luminous signal	No
Mounting method	Surface mounted/recessed mounted
Vertical fixing center distance	60-60 mm
Horizontal fixing center distance	60-60 mm
Contains Batteries and/or Accumulator	No

1 document

Select all

Instruction Use

LE02952AB.pdf pdf (0.97 Mo)

1 document

Select all

Catalogue Commercial Page

ex223001_0921.pdf pdf (0.05 Mo)

2 documents

Select all

Agreement

NFSSI Composant-DS 015 A2 (0.26 Mo)

PEP

LGRP-2015-223-V1-FR.pdf pdf (0.61 Mo)
