Name: X-LIGHT 360 Black recessed emergency lighting Permanent - Non Permanent 100 lumens 1H autotest
SKU: 660142BK

X-LIGHT 360 Black recessed emergency lighting Permanent - Non Permanent 100 lumens 1H autotest

X-LIGHT 360 Legrand

X-LIGHT 360 Black recessed emergency lighting Permanent - Non Permanent 100 lumens 1H autotest

REF. 660142BK EAN. 3414972634823

X-LIGHT 360 black allows perfect integration, round format directly recessed without accessories

Compare You can only compare 4 products, you must remove 1 to add this one

X-LIGHT 360 black allows perfect integration, round format directly recessed without accessories

Thanks to QR code engraved on emergency lighting unit, you have an instant access to data sheet, technical information... etc
X-light 360 offers a discreet solution for perfect integration into all types of buildings with Thickness 2 mm
Our packaging are 100% recyclable 0 Plasticand made at 80% from recycled carton

Mounting method	Built-in
Function	Escape route lighting/signage
Suitable for labelling type	Other
Type of indicator	Single-sided
With pictogram	No
Suitable for standby switching	Yes
Suitable for continuous circuit	Yes
With remote switch connection	No
Supplied remote control	No
Emergency function monitoring system	Automatic self test
Emergency power supply system	Peripheral (individual battery)
Battery technology	NiMH
Type of lithium-ion battery	Other
With heating element for battery	No
Lamp type	LED not exchangeable
With light source	Yes
Suitable for number of light sources	4
Lamp holder	None
Number of lighting heads	1
Housing material	Plastic
RAL-number housing	9005
Housing colour	Black
Material cover	Plastic, opal
Voltage type	AC/DC
Nominal voltage (Min-Max)	230-230 V
Nominal current (Min-Max)	43-43 mA
Type of control gear	LED operating device current-controlled
Light distributor	Diffuser lens/optic/panel
Constant light output (CLO)	Yes
Degree of protection (IP)	IP42
degree of impact strength (IK)	IK07
Protection class according to IEC 61140	II
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24	No
Luminous flux in emergency mode	100 lm
Rated luminous flux according to IEC 62722-2- 1 (Min-Max)	100-100 lm
Max. system power	1.6 W

Luminous flux in standby mode	100 lm
Colour temperature (Min-Max)	5000-5700 K
Nominal operation time (Min-Max)	1-1 h
Height/depth	44.5 mm
Outer diameter	125 mm
Built-in height/depth	42 mm
Built-in diameter	110 mm
Type of wiring	Loop-through wiring included
Number of poles	5
Conductor cross section	1.5 mm²
Connection type	Screw connection
Connectable conductor cross section (Min-Max)	1.5-2.5 mm²
Operating / setting temperature (Min-Max)	-5-35 °C
Storage temperature (Min-Max)	-10-50 °C
Frequency (Min-Max)	50-60 Hz
Estimated bulb life	100000 h
Mandatory neutral	Yes
Terminal marking indication	Yes
Halogen free	Yes
Cable nature for connection	Flexible or rigid
With complemantary luminous signal	No
Maximum Input cable diameter	12 mm
Cable support	Not applicable
Cable tie suitable with	Not applicable
Control mode	Wired
Contains Batteries and/or Accumulator	Yes
Addressable	No
IEC code (Pack1)	AAA
Battery ou Accumulator (Pack1)	Accumulator (rechargeable)
Element Composition (Pack1)	Nickel metal hydride
Number of Pack 1	1
Number of Single Element (Pack1)	3
Single Element weight (Pack1)	13 g
Pack1 Location	Product includes a battery
Regulation Type (Pack1)	I : Industrial (not Portable)
Connected object	No
