Name: Plexo™ - TV-R-SAT socket - Grey - mechanism
SKU: 069558L

Plexo™ - TV-R-SAT socket - Grey - mechanism

Plexo™ LEGRAND

Plexo™ - TV-R-SAT socket - Grey - mechanism

REF. 069558L EAN. 3414971878907

Compare You can only compare 4 products, you must remove 1 to add this one

Model	End socket
Type of socket outlet	TV/RD/SAT
DAB+	Yes
Mounting method	Other
Number of modules (module system)	3
Assembly arrangement	Other
Radio frequency band (Min-Max)	87.5-240 MHz
SAT frequency band (Min-Max)	950-2400 MHz
Type of fastening	Mounting with screw
Colour	Grey
RAL-number (similar)	7046
Surface protection	Untreated
Surface finishing	Matt

Material	Plastic
Material quality	Thermoplastic
Halogen free	Yes
Antimicrobial treatment	No
Degree of protection (IP)	IP55
degree of impact strength (IK)	IK08
Device width	70.5 mm
Device height	70.5 mm
Device depth	47.7 mm
Min. depth of built-in installation box	40 mm
Operating / setting temperature (Min-Max)	-5-35 °C
Storage temperature (Min-Max)	-10-70 °C
Terminal marking indication	Yes
