Plexo™ - Fused spur unit 66 - 1 gang - Double pole switched - 13 A 250 V~ - Grey

Name: Plexo™ - Fused spur unit 66 - 1 gang - Double pole switched - 13 A 250 V~ - Grey
SKU: 684645

Plexo™ LEGRAND

REF. 684645 EAN. 3245066846453

Compare You can only compare 4 products, you must remove 1 to add this one

Plexo 66 complete surface - mounting - IP 66 - IK 08 - Grey RAL 7016/TO 29 - Supplied with ISO 20 membrane glands and caps for rear cabling - For top or down cabling, plastic cable glands have to be used - Stainless steel captive terminal screws supplied in backed - off position
13 A - 250 V~ fused spur unit - Fitted with rear gasket with groove to deposit silicone - 1 gang - DP switched

Suitable for degree of protection (IP)	IP66
Device width	98 mm
Device height	98 mm
Device depth	70 mm
degree of impact strength (IK)	IK08
Operating / setting temperature (Min-Max)	-20-40 °C
Storage temperature (Min-Max)	-25-70 °C
Antimicrobial treatment	No
