Obria 1 gang Push Button 10A - Dark Silver

Name: Obria 1 gang Push Button 10A - Dark Silver
SKU: MEC23004SL

Obria Legrand

REF. MEC23004SL EAN. 3414972669092

The push-button is suitable for several everyday uses : lighting, door opening, the door bell, timer

Compare You can only compare 4 products, you must remove 1 to add this one

The push-button is suitable for several everyday uses : lighting, door opening, the door bell, timer

Sold as a complete set under one cat number
10A, 250V
Screw type terminals for enhanced contacts and open terminal for easy to install
Dark Silver Finish

Assembly arrangement	Basic element with housing top
Method of operation	Push button
Operating principle	Electromechanical
Contactless type	No
Number of rockers	1
Number of modules (module system)	2
Number of poles	1
Nominal voltage	250 V
Rated current	10 A
With lighting	No
With light source	No
With complemantary luminous signal	No
Monitoring contact	No
Connection type	Screwed terminal
Mounting method	Flush-mounted
Type of fastening	Screw mounting
Material	Plastic
Material quality	Thermoplastic
Halogen free	No
Antimicrobial treatment	No
Surface protection	Lacquered
Surface finishing	Matt
Colour	Silver

Transparent	No
Label space/information surface	No
Imprint	None
Suitable for degree of protection (IP)	IP20
degree of impact strength (IK)	IK04
Device width	86 mm
Device height	87.4 mm
Device depth	39.1 mm
Min. depth of built-in installation box	35 mm
Compatible with Apple HomeKit	No
Compatible with Google Assistant	No
Compatible with Amazon Alexa	No
IFTTT support available	No
Built-in depth	24.4 mm
Operating / setting temperature	-5-35 °C
Storage temperature	-10-70 °C
Voltage type	AC
Frequency	50-60 Hz
Mandatory neutral	No
Terminal marking indication	Yes
Terminals capacity	1-4 mm²
Cable nature for connection	Flexible or rigid
Cable section	1-4 mm²
