| Shape | Other |
|---|---|
| With name plate | No |
| With lighting | No |
| Lamp voltage (Min-Max) | 8-230 V |
| Material | Other |
| Mounting method | Surface mounted |
| Colour | Black |
| Wireless | No |
| Built-in depth | 29 mm |
| Width | 45 mm |
| Height | 135 mm |
| Degree of protection (IP) | IP4X |
| degree of impact strength (IK) | IK08 |
| Operating / setting temperature (Min-Max) | -10-40 °C |
| Storage temperature (Min-Max) | -10-25 °C |
| Voltage type | AC |
| RAL-number | 9017 |
| Halogen free | Yes |
| Connection type | Screwed terminal |
| Terminals capacity (Min-Max) | 0.4-1.5 mm² |
| Label space/information surface | No |
| Contains Batteries and/or Accumulator | Yes |
| IEC code (Pack1) | LP552035 |
|---|---|
| Battery ou Accumulator (Pack1) | Accumulator (rechargeable) |
| Element Composition (Pack1) | Lithium-ion |
| Number of Pack 1 | 1 |
| Number of Single Element (Pack1) | 1 |
| Single Element weight (Pack1) | 5.8 |
| Pack1 Location | Product includes a battery |
| Regulation Type (Pack1) | P : Portable (Standard format) |
| IEC code (Pack2) | LP552035 |
| Connected object | Yes |
| Operating method | Wifi network 2.4G |
| Application store for download | App Store , Google Play Store |
| With voice command | Yes |
| Programmable | Yes |
| Interoperable connection Protocol | Yes |
| Connectable by Internet box | Yes |
| Compatible voice assistants | Google Assistant , Apple Siri , Amazon Alexa |
| Product use function | Door entry systems |
| Application name | Home + Security |
| Programming way | Smartphone apps |
| Software Update Duration (years) | 3 |
