Name: Multifunction sleeve - vertical - for 2 rows cabinets
SKU: 001917

Multifunction sleeve - vertical - for 2 rows cabinets

Plexo³ LEGRAND

Multifunction sleeve - vertical - for 2 rows cabinets

REF. 001917 EAN. 3245060019174

Compare You can only compare 4 products, you must remove 1 to add this one

Mounting method	Surface mounted
number of rows	3
Width in number of modular spacings	0
Type of covering	Cover
Cover model	With notch
Transparent cover/door	No
Signal passing door	Yes
With lock	No
Type of closure	Other
Housing material	Plastic
Built-in depth	119 mm
Built-in height	428 mm
Built-in width	133 mm
Inner depth	48.5 mm
Earthing terminal block	No
Neutral terminal block	No

DIN-rail	No
With mounting plate	No
Extension possible	Yes
Colour	Grey
EMC-version	No
RAL-number	7046
Degree of protection (IP)	IP65
Height	432 mm
Width	137 mm
Depth	123 mm
degree of impact strength (IK)	IK09
Operating / setting temperature	-25-40 °C
Storage temperature	-25-55 °C
Halogen free	No
Fitted with rainproof plate protection	No
