Mallia Senses - Accessory - warm white led for locator - 230 volts

Name: Mallia Senses - Accessory - warm white led for locator - 230 volts
SKU: 281997ACC

Mallia Senses LEGRAND

REF. 281997ACC EAN. 3414972073639

Compare You can only compare 4 products, you must remove 1 to add this one

Electronic warm white led, provides illumination for locator function in soft light
MALLIA SENSES accessory

Assembly arrangement	Insert
Number of modules (module system)	1
Lamp holder	None
With light source	No
Lamp type	LED not exchangeable
With flashlight	No
With fixed symbol/imprint	Yes
With exchangeable symbol	No
Application as button	No
Mounting method	Other
Type of fastening	Other
Material	Other
Material quality	Other
Halogen free	Yes
Surface protection	Untreated
Surface finishing	Matt
Colour	Grey

Transparent	No
Colour light source	White
Suitable for degree of protection (IP)	IP20
Nominal voltage	250 V
degree of impact strength (IK)	IK04
Operating / setting temperature (Min-Max)	-5-50 °C
Storage temperature (Min-Max)	-10-70 °C
Voltage type	AC
Frequency (Min-Max)	50-60 Hz
Mandatory neutral	No
Terminal marking indication	No
Stress test conformity (1000V)	Yes
Antimicrobial treatment	No
Connection type	Not applicable
Cable nature for connection	Not applicable
Label space/information surface	No
