Living Now - rechargeable and removable torch, 230V, 2 modules

Name: Living Now - rechargeable and removable torch, 230V, 2 modules
SKU: BT-K4380

Living Now BTICINO

REF. BT-K4380 EAN. 8005543612514

Compare You can only compare 4 products, you must remove 1 to add this one

Push & pull extraction system (press and extract) complete with charging base - ON / OFF switch and SPOT button to increase brightness when necessary - Ni - MH interchangeable batteries without "memory" effect
The device must be completed with the type 04 cover
Screw and plate terminals
Easy installation and removal of the mechanism on the support frame thanks to the new generation of plastic hooking system
Low stand-by consumption 0.4 W - power supply 230 Va.c. - 2 modules

The torch lights up in the event of a blackout, allowing it to be extracted and used to reach the switchboard and reactivate the current

Mounting method	Built-in
Function	Escape route lighting
Suitable for labelling type	Other
Type of indicator	Single-sided
With pictogram	No
Suitable for continuous circuit	Yes
With remote switch connection	No
Supplied remote control	No
Emergency function monitoring system	None
Emergency power supply system	Central (central battery)
Battery technology	NiMH
Lamp type	LED not exchangeable
With light source	Yes
Lamp holder	None
Number of lighting heads	1
Housing material	Plastic
Housing colour	Other
Material cover	Plastic, opal
Voltage type	AC
Nominal voltage (Min-Max)	110-220 V
Type of control gear	Not required
Exchangeable control gear	No
Light distributor	Diffuser lens/optic/panel
Constant light output (CLO)	No
Degree of protection (IP)	IP30
degree of impact strength (IK)	IK04
Rated ambient temperature according to IEC 62722-2-1 (Min-Max)	-5-35 °C
Rated luminous flux according to IEC 62722-2- 1 (Min-Max)	0-0 lm
Colour temperature (Min-Max)	4000-5500 K

Recognition distance	5 m
Nominal operation time (Min-Max)	2-2 h
Width	45 mm
Height/depth	50 mm
Length	45 mm
Connectable conductor cross section (Min-Max)	0.5-1.5 mm²
Operating / setting temperature (Min-Max)	5-40 °C
Storage temperature (Min-Max)	-10-70 °C
Frequency (Min-Max)	50-60 Hz
Mandatory neutral	Yes
Terminal marking indication	No
Cable nature for connection	Flexible
With complemantary luminous signal	No
Maximum Input cable diameter	1.5 mm
Vertical fixing center distance (Min-Max)	3.5-3.7 mm
Horizontal fixing center distance (Min-Max)	3-3.2 mm
Cable support	Screw cable clamp
Cable tie suitable with	All conduit/cable types
Control mode	Wired
Contains Batteries and/or Accumulator	Yes
Addressable	No
Battery ou Accumulator (Pack1)	Accumulator (rechargeable)
Element Composition (Pack1)	Nickel metal hydride
Number of Pack 1	1
Number of Single Element (Pack1)	2
Single Element weight (Pack1)	10 g
Pack1 Location	Product includes a battery
Regulation Type (Pack1)	I : Industrial (not Portable)
Connected object	No

2 documents

Select all

Instruction Use

LE10379AA.pdf pdf (2.14 Mo)

Technical Sheet

ST-00000223-EN.pdf pdf (0.34 Mo)

1 document

Select all

Catalogue Commercial Page

ex223001_0768.pdf pdf (0.09 Mo)

1 document

Select all

BIM Data

BIM-BTICINO-LIVING-NOW-2025-ENGLISH.rvt rvt (152.05 Mo)
