Led shaverlight - ON/OFF - 800 lm - IP44 - 6.13x50 cm

SARLAM

Led shaverlight - ON/OFF - 800 lm - IP44 - 6.13x50 cm

REF. SL189810 EAN. 3292290504123
Download product sheet
You can only compare 4 products, you must remove 1 to add this one

Technical characteristics

Suitable for wall mounting Yes
Suitable for suspended mounting No
Suitable for ceiling mounting No
Suitable for built-in mounting No
Suitable for surface mounting Yes
Suitable for light line configuration No
Suitable for workplace according to EN 12464-1 Yes
Lamp type LED not exchangeable
With light source Yes
Suitable for number of light sources 1
Lamp holder Other
Housing material Plastic
Housing colour White
Material cover Plastic, opal
Type of grid None
Voltage type AC
Nominal voltage 207-253 V
Nominal current 28-34 mA
Type of control gear LED operating device voltage-controlled
With control gear Yes
Dimmable No
Dimming 0-10 V No
Dimming 1-10 V No
Dimming DALI No
Dimming DMX No
Dimming DSI No
Dimming manufacturer's proprietary system No
Dimming mains voltage modulation No
Dimming phase cut-off (trailing edge) No
Dimming phase cut-on (leading edge) No
Dimming programmable No
Dimming potentiometer (integrated) No
Dimming RF No
Dimming Touch and Dim No
Dimming Zigbee No
Dimming with push-button No
Light distributor Diffuser lens/optic/panel
Light distribution Symmetric
Beam angle > 80° - Extreme wide beam
Light outlet Direct
Degree of protection (IP), rear side IP44
degree of impact strength (IK) IK07
Protection class according to IEC 61140 II
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 Yes
Rated ambient temperature according to IEC 62722-2-1 -10-40 °C
Luminous flux in emergency mode 800 lm
Suitable for emergency lighting No
With movement sensor No
With light sensor No
With air slots No
Suitable for lamp power 7-7 W
Luminaire efficacy 0-0 lm/W
Max. system power 7 W
Rated luminous flux according to IEC 62722-2- 1 800-800 lm
Colour of light White
Colour temperature 3700-4300 K
Colour rendering index CRI 80-89
Width 61.5 mm
Height/depth 55.4 mm
Length 502 mm
Built-in width 202 mm
Connectable conductor cross section 1.5-2.5 mm²
Luminous intensity 0-0 cd
Compatible with Apple HomeKit No
Compatible with Google Assistant No
Compatible with Amazon Alexa No
IFTTT support available No
Operating / setting temperature -10-40 °C
Storage temperature -20-70 °C
Frequency 47-53 Hz
Standby consumption 0 mA
Estimated bulb life 40000 h
Mandatory neutral Yes
RAL-number 9003
Halogen free Yes
Antimicrobial treatment No
Cable nature for connection Rigid
With socket outlet No
Fitted with rainproof plate protection No
With complemantary luminous signal No
Supplied remote control No
Tube diameter for wall mounted product 0-15 mm
Maximum Input cable diameter 15 mm
Vertical fixing center distance 0-205 mm
Horizontal fixing center distance 0-205 mm
Cable support With zigzag
Auto switch No
Control mode Not applicable
Addressable No
Connected object No
