HRC blade type cartridge fuse - type gG - size 00 - 100 A - with indicator

Name: HRC blade type cartridge fuse - type gG - size 00 - 100 A - with indicator
SKU: 016345

LEGRAND

REF. 016345 EAN. 3245060163457

Compare You can only compare 4 products, you must remove 1 to add this one

HRC blade type cartridge fuses - gG/gL and aM types
Type gG / gL - Conform to IEC 60269 - 2 - For protection against accidental contacts, use terminal shields and fuse covers supplied with protection kits Size 00 - With indicator - Rating : 100 Amps - Voltage ~ : 500 Volts - Breaking capacity : 120000 Amps

Fuse construction type according to IEC 60269	NH00
Voltage type	AC/DC
Rated current	100 A
Rated voltage AC	500 V

Rated voltage DC	48 V
Utilization category according to IEC 60269	GG
Type of fuse status indicator	Top fuse status indicator
