HRC blade type cartridge fuse - type aM - size 0 - 100 A - with striker

Name: HRC blade type cartridge fuse - type aM - size 0 - 100 A - with striker
SKU: 016645

LEGRAND

REF. 016645 EAN. 3245060166458

Compare You can only compare 4 products, you must remove 1 to add this one

HRC blade type cartridge fuses - gG/gL and aM types
Type aM (motor rated) - Conform to EN 60269 - 1, IEC 60269 - 1, 2 and VDE 0636 - 1 - Fully insulated end plate and handle lugs Size - With striker - Rating : 100 Amps - Voltage ~ : 500 Volts - Breaking capacity : 120000 Amps

Fuse construction type according to IEC 60269	NH0
Voltage type	AC/DC
Rated current	100 A
Rated voltage AC	500 V

Rated voltage DC	48 V
Utilization category according to IEC 60269	AM
Type of fuse status indicator	Other

2 documents

Select all

Technical Sheet

F00190EN-06.pdf pdf (0.92 Mo)

Technical Sheet

F00190FR-06.pdf pdf (0.94 Mo)

1 document

Select all

Catalogue Commercial Page

ex223001_0264.pdf pdf (0.05 Mo)

1 document

Select all

PEP

LGRP-00952-V02.01-FR.pdf pdf (0.77 Mo)
