External angle for Snap-on DLP-S trunking 85x50mm

DLP-S LEGRAND

External angle for Snap-on DLP-S trunking 85x50mm

REF. 638028 EAN. 3414970446558
Download product sheet
You can only compare 4 products, you must remove 1 to add this one
Product characteristics
  • Variable angle of 80 to 120 degrees
  • Delivered with an adaptator allowing to fixe the accessory on the trunking
  • Respect the protection index
  • Improvement of aesthetics (covering of the cut)
  • Colour: white
Recommendation / Restriction
  • Can not be used outside

The product's benefits

Installation
  • Clippes directly on the trunking
Usage
  • Allows a neat and clean electrical installation finish

Technical characteristics

Number of covers 0
Cover width 1 0 mm
Cover width 2 0 mm
Cover width 3 0 mm
Symmetric Yes
Model Moulded hood
Angle (Min-Max) 90-90 °
Material Plastic
Material quality Other
Halogen free Yes
Antimicrobial treatment No
Surface protection Untreated
Colour White
RAL-number 9003
With protective foil No
With duct connector No
Bottom perforation No
Mounting method cover Spanned
With cable fixing clip No
Degree of protection (IP) Other
degree of impact strength (IK) Other
Operating / setting temperature (Min-Max) -5-60 °C
Width 85 mm
Depth 50 mm
Storage temperature (Min-Max) -25-60 °C

Documentation

2 documents
Technical Sheet
F01198FR-07.pdf pdf (3.26 Mo)
Technical Sheet
F01198EN-08.pdf pdf (3.25 Mo)
1 document
Catalogue Commercial Page
ex223001_1082.pdf pdf (0.14 Mo)
1 document
PEP
LGRP-01519-V01.01-EN.pdf pdf (0.59 Mo)
