Name: Energy Webserver to configure, control and remotely visualize Legrand energy management offers.
SKU: 414949

Energy Webserver to configure, control and remotely visualize Legrand energy management offers.

LEGRAND

Energy Webserver to configure, control and remotely visualize Legrand energy management offers.

REF. 414949 EAN. 3414971122512

Compare You can only compare 4 products, you must remove 1 to add this one

Management of 255 Modbus addresses from Legrand offers (metering, measurement, status or command)
Vizualisation and control dashboard displayed via internet browser via secure web pages (https ...) .
Auxiliary power supply : 12V DC ± 10%, by an external power supply, supplied with theWeb server.

Webserver supplied with brackets to be used to fix it in a rack cabinet, on the bottom of a cabinet or cabinet using screws or DIN rail

Ready-to-use dashboard (embedded web pages)to visualize Legrand energy management offers.

A wide range of Legrand offers managed: EMS CX3, measurement offers, charging stations for electric vehicles ...

Supply voltage DC (Min-Max)	12-12 V
Voltage type (supply voltage)	DC
Supporting protocol for TCP/IP	Yes
Supporting protocol for PROFIBUS	No
Supporting protocol for CAN	No
Supporting protocol for INTERBUS	No
Supporting protocol for ASI	No
Supporting protocol for KNX	No
Supporting protocol for Modbus	No
Supporting protocol for Data-Highway	No
Supporting protocol for DeviceNet	No
Supporting protocol for SUCONET	No
Supporting protocol for LON	No
Supporting protocol for SERCOS	No
Supporting protocol for PROFINET IO	No
Supporting protocol for PROFINET CBA	No
Supporting protocol for Foundation Fieldbus	No
Supporting protocol for EtherNet/IP	Yes
Supporting protocol for AS-Interface Safety at Work	No
Supporting protocol for DeviceNet Safety	No
Supporting protocol for INTERBUS-Safety	No
Supporting protocol for PROFIsafe	No
Supporting protocol for SafetyBUS p	No
Supporting protocol for other bus systems	No

Radio standard Bluetooth	No
Radio standard WLAN 802.11	No
Radio standard GPRS	No
Radio standard GSM	No
Mobile communications standard 3G (UMTS)	No
IO link master	No
System accessory	Yes
Degree of protection (IP)	IP2X
With potential separation	Yes
Fieldbus connection over separate bus coupler possible	No
Suitable for rail mounting	No
Wall mounting/direct mounting	Yes
Front built-in possible	No
Rack-assembly possible	Yes
Suitable for safety functions	Yes
SIL according to IEC 61508	None
Performance level according to EN ISO 13849-1	None
Appendant operation agent (Ex ia)	No
Appendant operation agent (Ex ib)	No
Explosion safety category for gas	None
Explosion safety category for dust	None
Width	133.4 mm
Height	104.2 mm
Depth	43.1 mm
