Connecting terminal block, screw connection, 2 connections 2entry/2outlets led, Cross-section 4mm² - pitch 5mm -grey

Viking 3 LEGRAND

Connecting terminal block, screw connection, 2 connections 2entry/2outlets led, Cross-section 4mm² - pitch 5mm -grey

REF. 037256 EAN. 3245060372569
Download product sheet
You can only compare 4 products, you must remove 1 to add this one
Product characteristics
  • Grey terminal blocks are recommended for standard circuits.
  • Direct tool - free insertion of a rigid wire or a flexible wire with ferrules, up to 6mm pitch
  • 2 areas for automatic insertion bridging combs (upper level only for multi-level terminal blocks)
  • Easy insertion of conductors thanks to the ergonomic shape of the entry and outlet.
Recommendation / Restriction
  • Installation recommended for electrical connection in industrial and tertiary cabinets and enclosures.

The product's benefits

Installation
  • A securing pin on the insulating body holds the Viking 3 terminal blocks together for ease of handling and perfect alignment on the rail. The assembly/disassembly of a terminal block is still possible without removing the adjacent terminal blocks
Usage
  • Terminal blocks have two marking zones per level allowing a clear, visible and convenient identification of the circuit.

Technical characteristics

Connectable conductor cross section fine-strand without cable end sleeve 0.5-6 mm²
Connectable conductor cross section fine-strand with cable end sleeve 0.5-2.5 mm²
Connectable conductor cross section solid-core 0.5-6 mm²
Connectable conductor cross section multi-wired 0.5-4 mm²
Rated voltage 24 V
Type of electrical connection 1 Spring clamp connection
Type of electrical connection 2 Spring clamp connection
Number of levels 2
Number of clamp positions per level 2
Mounting method DIN rail (top hat rail) 35 mm
Material insulation body Thermoplastic
Operating temperature -5-40 °C
Width 5 mm
Height 56 mm
Depth 90 mm
Explosion-tested version 'Ex e' No
Closing plate required Yes
Colour Grey
Internally connected stages Yes
Inflammability class of insulation material according to UL 94 V2
