Name: Circuit breaker DPX3 630,4 poles, with rated current of 630A and rotary knob electronic protection unit.
SKU: 422567

Circuit breaker DPX3 630,4 poles, with rated current of 630A and rotary knob electronic protection unit.

DPX³ 630 LEGRAND

Circuit breaker DPX3 630,4 poles, with rated current of 630A and rotary knob electronic protection unit.

REF. 422567 EAN. 3414970383334

Compare You can only compare 4 products, you must remove 1 to add this one

Breaking capacity of 50kA, according to EN/IEC standard 60947 - 2, suitable for protection of high power industrial installations. Rated insulation voltage of 800V Rated impulse withstand voltage of 8kV
Compliat with NEMA AB‐1. Climatic condition according to IEC/EN 60947 - 1 Annex Q, Cat. F subject to temperature, humidity, vibration, shock and salt mist.
Electronic protection unit with rotary knobs for regulation of thermal current and magnetic current. Thermal protection within range of 0,4 - 1,0 of the rated current. Magnetic protection within range of 1,5 - 10 of the rated current.
Can be equipped with releases (undervoltage and shunt releases) and auxiliary contacts. Can used with rotary handles or motor operator. Locking accessories are available.
Has diffent type of possible connection accessories: cage terminals, spreader and rear terminals. Is available also in a plug-in version (circuit breaker fitted with special terminals and mounted on a plug-in base) or in a draw-out version (a plug-in version fitted with a "Debro-lift" mechanism which can be used to withdraw the breaker while keeping it on its base)

DPX3 platform has been developed to give a new solution of protection devices for a more precise approach in power installations in order to offer the correct answer for different project needs.

DPX3 platform provide a complete "project" approach in premium market segment, offering a range completely suitable for high power application

DPX3 630 is the answer for the competition in the project sub-segment. A unique size for all versions (thermal magnetic, electronic with or without measure). Earth leakage fetures can be achieved by adding a dedicated module at the bottom of the breaker itself.

Rated permanent current Iu	1600 A
Rated voltage	220-690 V
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz	70 kA
Overload release current setting	640-1600 A
Adjustment range short-term delayed short-circuit release	960-16000 A
Adjustment range undelayed short-circuit release	20000-20000 A
Device construction	Built-in device fixed built-in technique
Integrated earth fault protection	No
Type of electrical connection of main circuit	Screw connection
Suitable for DIN rail (top hat rail) mounting	No
DIN rail (top hat rail) mounting optional	No

Number of auxiliary contacts as change-over contact	3
With switched-off indicator	Yes
With integrated under voltage release	Yes
Number of poles	3
Position of connection for main current circuit	Front side
Type of control element	Wing knob
Complete device with protection unit	Yes
Motor drive integrated	No
Motor drive optional	Yes
Degree of protection (IP)	IP30

Circuit breaker DPX3 630,4 poles, with rated current of 630A and rotary knob electronic protection unit.
