Bell - 230 V~ - 6 VA - 1 mod

Name: Bell - 230 V~ - 6 VA - 1 mod
SKU: 004107

Lexic LEGRAND

REF. 004107 EAN. 3245060041076

Compare You can only compare 4 products, you must remove 1 to add this one

Housing colour	Grey
Housing material	Plastic
Nominal voltage (Min-Max)	230-230 V
Type of current	AC
Built-in battery	No
Electricity consumption (Min-Max)	0.027-0.027 A
Connection type	Screwed terminal
Loudness	83 dB
Wireless	No
Degree of protection (IP)	IP20
Degree of protection (NEMA)	Other
Width in number of modular spacings	1
Width	17.7 mm
Height	77.8 mm
Depth	94.8 mm
degree of impact strength (IK)	IK05
Operating / setting temperature (Min-Max)	-10-60 °C
Storage temperature (Min-Max)	-10-60 °C

Frequency (Min-Max)	50-60 Hz
Standby consumption	27 mA
Terminal marking indication	Yes
RAL-number	7035
Halogen free	No
Antimicrobial treatment	No
Terminals capacity (Min-Max)	1.5-10 mm²
Cable nature for connection	Flexible or rigid
Label space/information surface	Yes
With complemantary luminous signal	No
Contains Batteries and/or Accumulator	No
Number of ringtones	1
Connected object	No
Application store for download	Not applicable
With voice command	No
Programmable	No
Connectable by Internet box	No

1 document

Select all

Catalogue Commercial Page

ex223001_0110.pdf pdf (0.1 Mo)

1 document

Select all

3D Autocad

004107.dwg dwg (0.12 Mo)
