Name: BAP RTC - Twin LEDs Spotlight Emergency Unit - 2500lm output - 1h duration - IP65 protection - Product
SKU: 661463

BAP RTC - Twin LEDs Spotlight Emergency Unit - 2500lm output - 1h duration - IP65 protection - Product

Legrand

BAP RTC - Twin LEDs Spotlight Emergency Unit - 2500lm output - 1h duration - IP65 protection - Product

REF. 661463 EAN. 3414972656078

Legrand BAP RTC LED Spotlight: 2500lm, 1hr non-maintained, IK07, IP65, wall/ceiling mount, for high-ceiling areas.

Compare You can only compare 4 products, you must remove 1 to add this one

Legrand BAP RTC LED Spotlight: 2500lm, 1hr non-maintained, IK07, IP65, wall/ceiling mount, for high-ceiling areas.

Multi-mode installation and support (wall & ceiling mounting, cable tray, metal/concrete pillars)
Solid fixation to secure installations
The lightest twinspot on the market

Mounting method	Wall surface mounted
Function	Escape route lighting/signage
Suitable for labelling type	Other
With pictogram	No
Suitable for standby switching	Yes
Suitable for continuous circuit	No
With remote switch connection	No
Supplied remote control	Yes
Emergency function monitoring system	Test button
Emergency power supply system	Peripheral (individual battery)
Battery technology	Lithium-ion
Type of lithium-ion battery	Lithium iron phosphate (LiFePO4)
With heating element for battery	No
Lamp type	LED not exchangeable
With light source	Yes
Suitable for number of light sources	8
Lamp holder	None
Number of lighting heads	2
Housing material	Plastic
RAL-number housing	9011
Housing colour	Black
Material cover	Plastic, transparent
Voltage type	AC
Nominal voltage	207-253 V
Nominal current	12-62 mA
Type of control gear	LED operating device current-controlled
Exchangeable control gear	No
Light distributor	Refractor lens
Constant light output (CLO)	Yes
Degree of protection (IP)	IP65
degree of impact strength (IK)	IK07
Protection class according to IEC 61140	II
Luminous flux in emergency mode	2500 lm
Rated luminous flux according to IEC 62722-2- 1	2500-2500 lm

Max. system power	0.9 W
Colour temperature	5000-6500 K
Nominal operation time	1-1 h
Width	240 mm
Height/depth	93.5 mm
Length	285.5 mm
Number of poles	2
Connection type	Other
Connectable conductor cross section	1.5-2.5 mm²
Operating / setting temperature	0-35 °C
Storage temperature	-10-50 °C
Frequency	50-60 Hz
Mandatory neutral	Yes
Terminal marking indication	Yes
Halogen free	Yes
Cable nature for connection	Rigid
With complemantary luminous signal	Yes
Vertical fixing center distance	163.6-164.4 mm
Horizontal fixing center distance	163.6-164.4 mm
Cable support	Cable gland
Cable tie suitable with	Not applicable
Control mode	Wired
Contains Batteries and/or Accumulator	Yes
Addressable	No
IEC code (Pack1)	3IFpR27/67
Battery ou Accumulator (Pack1)	Accumulator (rechargeable)
Element Composition (Pack1)	Lithium-Iron-Phosphate
Number of Pack 1	2
Number of Single Element (Pack1)	3
Single Element weight (Pack1)	84 g
Pack1 Location	Product includes a battery
Regulation Type (Pack1)	I : Industrial (not Portable)
Connected object	No
