Art d'Arnould - 1 gang fused connection unit 13A-250V W/ power indicator Epure - Brushed Steel

Art d'Arnould LEGRAND

Art d'Arnould - 1 gang fused connection unit 13A-250V W/ power indicator Epure - Brushed Steel

REF. AR-68151 94 EAN. 3233625159076

1 gang fused connect unit 13A-250V w/ power ind British Standard -Epure brushed steel

Download product sheet
You can only compare 4 products, you must remove 1 to add this one

Description

1 gang fused connect unit 13A-250V w/ power ind British Standard -Epure brushed steel

Product characteristics
  • Perfectly adapting to the spirit and use of the place, this function offers architects and decorators the means to shape, design, and model spaces
  • Chrome finish
  • Colors and appearances may vary from one plate to another due to their handcrafted manufacturing
  • Mounted in a flush-mounted box according to your wall type and the number of functions in your installation
Recommendation / Restriction
  • It is recommended to install the plates only after the wall coatings have been completely finished (paint, fabrics, etc.). Indoor use only

The product's benefits

Avantages
  • Expertly handcrafted
  • Made from solid, genuine brass

Technical characteristics

Connection type Screw connection
Mounting method Front mounting
Type of current AC
Rated current 13 A
Rated voltage 250 V
Dimensions glass fuse 5x25 mm
Width 86 mm
Height 86 mm
Depth 29.5 mm
Built-in depth 23.5 mm
degree of impact strength (IK) IK02
Degree of protection (IP) IP21
Operating / setting temperature -5-35 °C
Storage temperature -10-70 °C
Frequency 50-60 Hz
Terminal marking indication Yes
Colour Silver
Halogen free Yes
Antimicrobial treatment No
Number of terminals 6
Terminals capacity 2.5-6 mm²
Cable nature for connection Flexible or rigid

Documentation

1 document
Technical Sheet
F03065EN-00.pdf pdf (0.15 Mo)
1 document
Catalogue Commercial Page
ex223001_0715.pdf pdf (0.08 Mo)
