Name: 180° motion sensor -IP40 -8 m -flush-mounting -without override -PIR -cardboard
SKU: 078458

180° motion sensor -IP40 -8 m -flush-mounting -without override -PIR -cardboard

Legrand

180° motion sensor -IP40 -8 m -flush-mounting -without override -PIR -cardboard

REF. 078458 EAN. 3414970566225

Compare You can only compare 4 products, you must remove 1 to add this one

2 - wire motion sensors, without neutral - IR detection - Accepted power by lamp type : - LEDs : 3 to 100 W - Compact fluorescent : 3 to 100 W - LEDs, CFLs, Halogen, fluo tubes with ferromagnetic or electronic transformer : 3 to 250 VA - Halogen 230 V, incandescent : 3 to 250 W - For LED and compact fluorescent lamps - If several sensors are installed on the same circuit, the minimum load changes : refer to the technical sheet - Possibility to install up to 3 sensors in parallel - Time delay setting from 10 s to 10 min - Light level threshold setting from 5 lux to 1275 lux - Standby consumption : 0,2 WSensor without override - White
Infrared and ultrasonic Lighting Management sensors for workplaces, allowing precise presence detection as soon as the wave transmitted by the sensor is modified (for example, by hand movement on a keyboard)

2-wire motion sensors, without neutral- IR detection- Accepted power by lamp type:- LEDs: 3 to 100 W- compact fluorescent: 3 to 100 W- LEDs, CFLs, Halogen, fluo tubes with ferromagnetic or electronic transformer: 3 to 250 VA- halogen 230 V, incandescent: 3 to 250 W- For LED and compact fluorescent lamps- If several sensors are installed on the same circuit, the minimum load changes: refer to the technical sheet- Possibility to install up to 3 sensors in parallel- Time delay setting from 10 s to 10 min- Light level threshold setting from 5 lux to 1275 lux- Standby consumption : 0.2 WSensor without override - White
- Infrared and ultrasonic Lighting Management sensors for workplaces, allowing precise presence detection as soon as the wave transmitted by the sensor is modified (for example, by hand movement on a keyboard)

Model	Movement sensor
Movement sensor/presence detector technology	Passive infrared
Constant light control	Yes
HVAC-control	No
Forced switch off	Yes
Animal zone	No
Creep-under protection	No
Background monitoring	No
Networkable	No
Optimum mounting height	1.2 m
Staircase light controller	Yes
Bridging switch	Yes
Max. reach sideways	6 m
Max. reach frontally	8 m
Diameter reach on floor	8 m
Suitable for wireless transmission	No
Remote operation	No
Supplied remote control	No
Response value sensitivity adjustable	No
Response value luminosity adjustable	Yes
With signal unit	Yes
Teach-function for response value luminosity	No
Dim function with dimmer basic element	No
Mounting method	Flush-mounted
Suitable for ceiling mounting	No
Suitable for wall mounting	Yes
Connection type	Screwed terminal
Material	Plastic
Material quality	Thermoplastic
Halogen free	No
Surface protection	Untreated
Surface finishing	Glossy
Antimicrobial treatment	No
Colour	White
RAL-number (similar)	9003
Transparent	No

Degree of protection (IP)	IP40
degree of impact strength (IK)	IK04
Voltage type	AC
Frequency (Min-Max)	50-60 Hz
Nominal voltage (Min-Max)	230-230 V
Min. switch-on time	10 s
Max. duty cycle	10 min
Switch-off delay	0 s
Switching-on delay	0 s
Detection angle horizontal (Min-Max)	-60-60 °
Pivoting range sensor, horizontal (Min-Max)	0-0 °
Pivoting range sensor, vertical (Min-Max)	0-0 °
Response value luminosity (Min-Max)	5-1275 lx
Max. switching power	250 W
Max. starting current	1.8 A
Control current	1.8 mA
Substation input	No
With alarm function	No
With acoustic sensor	No
Ambient temperature (Min-Max)	-5-35 °C
Width	45 mm
Height	45 mm
Depth	52 mm
Built-in depth	34 mm
Min. depth of built-in installation box	40 mm
With connection cable	No
Connection cable length	0 mm
Compatible with Apple HomeKit	No
Compatible with Google Assistant	No
Compatible with Amazon Alexa	No
IFTTT support available	No
Operating / setting temperature (Min-Max)	-5-35 °C
Storage temperature (Min-Max)	-20-70 °C
Terminals capacity (Min-Max)	2.5-2.5 mm²
Auto switch	Yes

180° motion sensor -IP40 -8 m -flush-mounting -without override -PIR -cardboard
