Buzzer Mosaic - 8 V~ - 2 modules
Mosaic™
LEGRAND
Buzzer Mosaic - 8 V~ - 2 modules
REF. 076640
EAN.
3245060766405
Share
You can only compare 4 products, you must remove 1 to add this one
Technical characteristics
| Type of current | AC |
|---|---|
| Electricity consumption | 0.37 A |
| Degree of protection (IP) | IP41 |
| Loudness | 65 dB |
| Housing material | Plastic |
| Housing material quality | Other |
| Surface protection housing | Untreated |
| Housing colour | White |
| Type of tone | Continuous tone |
| Mounting method | Built-in |
| Built-in transformer | No |
| Width | 45 mm |
| Height | 45 mm |
| Depth | 41 mm |
|---|---|
| Built-in depth | 32 mm |
| degree of impact strength (IK) | IK05 |
| Operating / setting temperature | -5-+35 °C |
| Storage temperature | -10-+70 °C |
| Frequency | 50-60 Hz |
| Halogen free | Yes |
| Connection type | Screwed terminal |
| Number of terminals | 2 |
| Terminals capacity | 1.5-1.5 mm² |
| Cable nature for connection | Flexible |
| Cable section | 1.5-1.5 mm² |
| Loudness setting | No |
