2 independent relay actuator – for single and double loads.

My Home Up BTICINO

2 independent relay actuator – for single and double loads.

REF. F430/2 EAN. 8012199667690
Download product sheet
You can only compare 4 products, you must remove 1 to add this one
Product charateristics
  • 2 DIN modules
  • Rated voltage 27 V d.c.
  • Rated current 0,025 A
  • Height 90 mm
  • 2 contacts

Technical characteristics

Bus system KNX No
Bus system KNX-RF (Radio Frequent) No
Bus system radio frequent No
Bus system LON No
Bus system Powernet No
Other bus systems Other
Mounting method DRA (DIN-rail adapter)
Width in number of modular spacings 2
Local operation/hand operation Yes
With LED indication Yes
Number of digital inputs 0
Suitable for C-load No
Max. number of switching contacts 2
Rated current 6 A
Rated operating voltage 240-240 V
Different phases connectable No
With bus connection Yes
Modular expandability No
Degree of protection (IP) IP20
Connected object No
Product use function Thermal comfort management

Documentation

2 documents
Technical Sheet
ST-00000902-FR.pdf pdf (0.35 Mo)
Technical Sheet
ST-00000902-EN.pdf pdf (0.35 Mo)
1 document
Catalogue Commercial Page
ex223001_0648.pdf pdf (0.09 Mo)
