Pack control Céliane black with french standard socket for a connected installation

Céliane Legrand

Pack control Céliane black with french standard socket for a connected installation

REF. CN0443B EAN. 3414972838658

Pack Control for a connected installation allows you to control your lighting, roller shutters & electrical appliances remotely via the Home + Control app or by using your voice, and to track your appliances consumption from your smartphone

Download product sheet
Finition :
You can only compare 4 products, you must remove 1 to add this one

Description

Pack Control for a connected installation allows you to control your lighting, roller shutters & electrical appliances remotely via the Home + Control app or by using your voice, and to track your appliances consumption from your smartphone

Product characteristics
  • Gateway: Enjoy seamless setup with Home + Pro and daily effortless control of your installation with Home + Control.
  • Take advantage of the Gateway to connect and expand your Legrand ecosystem. The Gateway allows you to easily add compatible products, set schedules, and automate your home for greater experience.
  • Simple setup with the built-in configuration button. Quick and automatic network creation, with easy product pairing—no app required, but recommended for managing your home setup efficiently.
  • Sleek design, easily installed in a standard 40mm outlet.
  • Black
Recommendation / Restriction
  • No Wi-Fi needed for setup.Wi-Fi and internet connection required for full Home + Control app experience.

The product's benefits

Installation
  • The Celiane with Netatmo gateway power outlet is easily installed in place of an existing standard power outlet and needs a standard-depthflush-mounting box (40 mm). Claw or screw fixing possible.
Usage
  • Enjoy the full benefits of the connected offer with Netatmo : Improve your comfort by automating roller shutter management with personalized schedules. Optimize your lighting with life scenarios like "arrival mode", "movie night" and control your Zigbee-compatible LED lights, bulbs and strips to add style and atmosphere to your home. Secure your absence with presence simulation scenarios. Monitor your energy consumption effortlessly through the Home + Control app.
Avantages
  • The installation of a Celiane with Netatmo is identical as a traditionnal electrical installation. It does not need any additional wire and is placed in a standard one gang box of 40mm depth with or without claws.
  • Effortless control with Voice Assistant. Manage your home hands-free with Celiane with Netatmo products, using Apple Siri, Google Home or Amazon Alexa. Just say “I’m leaving” or “Good night” to turn off selected lights, appliances, and close your shutters—all with a simple voice command.
  • When installed on the wall , the Gateway and socket perfectly match the sleek aesthetic of all Celiane with Netatmo products, blending effortlessly into your home’s decor when installed on the wall.

Technical characteristics

Standby consumption 5.4
Bus system KNX No
Bus system KNX-RF (Radio Frequency) No
Bus system radio frequency Yes
Bus system LON No
Bus system Powernet No
Other bus systems Zigbee
Radio frequency bidirectional Yes
Model Multiple interface
Mounting method Flush-mounted
Max. number of devices per channel 100
Demounting protection No
With LED indication No
Updateable Yes
Operating voltage (Min-Max) 110-230 V
Voltage type AC
Protocol TCP/IP
Provider dependent No
Visualization Yes
Web-Server No
Radio interface Yes
IR interface No
Degree of protection (IP) IP40
Width 71 mm
Height 51.5 mm
Depth 145 mm
degree of impact strength (IK) IK04
Operating / setting temperature (Min-Max) 5-35 °C
Storage temperature (Min-Max) 0-45 °C
Terminal marking indication Yes
Type of load Not applicable
Halogen free Yes
Connection type Push-in clamp , Cable
Number of distribution blocks 6
Terminals capacity (Min-Max) 0.75-2.5 mm²
Label space/information surface No
Fitted with USB plug No
Contains Batteries and/or Accumulator No
Addressable No
Connected object Yes
Operating method Wifi network 2.4G , Zigbee
Application store for download App Store , Google Play Store
With voice command Yes
Programmable Yes
Interoperable connection Protocol Yes
Connectable by Internet box Yes
Compatible voice assistants Google Assistant , Amazon Alexa , Apple Siri
Product use function Connected devices interface
Application name Home + Control
Programming way Smartphone apps

Documentation

1 document
Instruction Use
LE15106AA.pdf pdf (4.83 Mo)
1 document
BIM Data
2 documents
Agreement
PEP
LGRP-02049-V01.01-FR.pdf pdf (0.84 Mo)
