Niloé - Surface mounting box 1-gang medium grey - IP2X protection - Halogen free thermoplastic - 88.5x88.5x42mm square form factor

Niloé Legrand

Niloé - Surface mounting box 1-gang medium grey - IP2X protection - Halogen free thermoplastic - 88.5x88.5x42mm square form factor

REF. NP161MG EAN. 3414972810371
The Niloé surface mounting box features robust thermoplastic construction, IP2X protection, and shock resistance. Compatible with 1-gang plates, it allows horizontal or vertical mounting for secure installation.
Download product sheet
You can only compare 4 products, you must remove 1 to add this one

Description

The Niloé surface mounting box features robust thermoplastic construction, IP2X protection, and shock resistance. Compatible with 1-gang plates, it allows horizontal or vertical mounting for secure installation.

Product characteristics
  • Plastic support frame constructed from halogen-free thermoplastic ensures high rigidity and resistance.
  • Recyclable paper box packaging designed for convenient handling and professional installation.
  • Surface mounting box supports 1-gang modular switching devices with both horizontal and vertical orientation.
  • Matte medium grey lacquered finish provides enhanced durability and modern aesthetics.
  • Ingress protection rating of IP2X and impact resistance of IK02 for reliable indoor use.
Recommendation / Restriction
  • To be used indoor only.

The product's benefits

Installation
  • Slot system allows a perfect and easy multigang setting. The support frames can be perfectly joined thereby easing the installation.
Avantages
  • Matte Medium Grey finishing

Technical characteristics

Antimicrobial treatment No
Assembly arrangement Surface mounted frame
Suitable for modular domestic switching devices Yes
Number of modules (module system) 1
Number of units 1
Mounting direction Horizontal and vertical
Shape Square
Material Plastic
Material quality Thermoplastic
Halogen free Yes
Surface protection Lacquered
Surface finishing Matt
Colour Grey
Transparent No
With cover frame No
With duct entry Yes
With cable entry Yes
With screw gland entry No
Shock resistant Yes
Degree of protection (IP) IP2X
Width 88.5 mm
Height 88.5 mm
Depth 42 mm
degree of impact strength (IK) IK02
Operating / setting temperature (Min-Max) -5-40 °C
Storage temperature (Min-Max) -10-70 °C
Entry membrane gland type Not applicable
Cable support Not applicable

Documentation

1 document
Technical Sheet
F04334EN-00.pdf pdf (0.82 Mo)
