Name: Mosaic - Connected starter pack wireless master switch home/away + gateway outlet - Zigbee/WiFi 2.4G - Voice control - IP40
SKU: 077700

Mosaic - Connected starter pack wireless master switch home/away + gateway outlet - Zigbee/WiFi 2.4G - Voice control - IP40

REF. 077700 EAN. 3414971015951

Starter pack for connected installation enables remote control of lighting, roller shutters, and appliances via Home + Control app or voice commands. Monitor energy consumption. Compatible with Amazon Alexa, Google Assistant, and Apple

Compare You can only compare 4 products, you must remove 1 to add this one

Description

Product characteristics

Gateway power outlet measures instantaneous and total electricity consumption, provides overload protection with 16A max breaking, supports Wi-Fi 2.4GHz 802.11b/g/n, and features an app-activated LED locator; compatible with all electrical and large household appliances.
Home/Away wireless master switch enables customizable predefined scenarios via the Home + Control app, operates with a replaceable CR2032 lithium battery offering 8-year life, and includes an LED indicator with low battery warning.
Gateway outlet installs easily by replacing a standard outlet in a 1-gang box with 40mm depth, supporting both claw and screw mounting for streamlined integration.
Wireless remote master switch features an 8-year lifetime replaceable battery, with in-app low battery alerts for maintenance efficiency.
White finish aligns with Mosaic aesthetics for seamless integration into modern electrical installations.

Recommendation / Restriction

A Wi-Fi connection via your router is required.

The product's benefits

Installation

The Mosaic with Netatmo gateway power outlet is easily installed in place of an existing standard power outlet and needs a standard-depth flush-mounting box (40mm). Claw or screw fixing possible.

Usage

Voice control of your lights and electrical appliances via a voice assistant

Avantages

The installation of a Mosaic with Netatmo is identical as a traditionnal product. It does not need any additional wire and is placed in a standard one gang box of 40mm depth with or without claws.
Simply control your house with the Mosaic with Netatmo products by voice control (via Apple Siri and Google Home). Simply saying "I am leaving" or "Good night" to your smartphone, you can swith off both selected lights, appliances and close all shutters.
When installed on the wall, the wireless remote master switch has the same aesthetic and thickness as all the Mosaic with Netatmo switches.

Technical characteristics

Bus system KNX	No
Bus system KNX-RF (Radio Frequency)	No
Bus system radio frequency	Yes
Bus system LON	No
Bus system Powernet	No
Other bus systems	Zigbee
Radio frequency bidirectional	Yes
Model	Multiple interface
Mounting method	Flush-mounted
Max. number of devices per channel	100
Demounting protection	Yes
With LED indication	No
Updateable	Yes
Operating voltage (Min-Max)	230-250 V
Voltage type	AC
Protocol	TCP/IP
Provider dependent	No
Visualization	Yes
Web-Server	No
Radio interface	Yes
IR interface	No
Degree of protection (IP)	IP40
degree of impact strength (IK)	IK04
Operating / setting temperature (Min-Max)	5-45 °C
Storage temperature (Min-Max)	0-45 °C
Terminal marking indication	Yes
Type of load	Not applicable

Halogen free	Yes
Connection type	Push-in clamp , Cable
Terminals capacity (Min-Max)	0.75-2.5 mm²
Label space/information surface	No
Fitted with USB plug	No
Contains Batteries	Yes
Addressable	No
Number of batteries (Type 1)	1
IEC code (Type 1)	CR2032
Battery ou Accumulator (Type 1)	Battery (not rechargeable)
Battery Composition (Type 1)	Lithium (battery or accumulator)
Battery Location (Type 1)	Product includes a battery
Regulation Type (Type 1)	P : Portable (Standard format)
Connected object	Yes
Operating method	Wifi network 2.4G , Zigbee
Application store for download	App Store , Google Play Store
With voice command	Yes
Programmable	Yes
Interoperable connection Protocol	Yes
Connectable by Internet box	Yes
Compatible voice assistants	Google Assistant , Amazon Alexa , Apple Siri
Product use function	Connected devices interface
Application name	Home + Control
Programming way	Smartphone apps
Battery weight (g) for Type 1	3 g
Number of Single Element (Pack1)	1
