DO NOT disturb/make UP room command matt white altair - DND/MUR command MW - 240V push button - Matt white thermoplastic basic element

Arteor Advance Legrand

DO NOT disturb/make UP room command matt white altair - DND/MUR command MW - 240V push button - Matt white thermoplastic basic element

REF. AA27109MW EAN. 3414972969185
The DO NOT disturb/make UP room command matt white altair is a 240V push button module for hotel room status control. Its matt white thermoplastic front, lacquered RAL9003 finish and 34.5mm depth suit 40mm boxes.
Download product sheet
You can only compare 4 products, you must remove 1 to add this one

Description

The DO NOT disturb/make UP room command matt white altair is a 240V push button module for hotel room status control. Its matt white thermoplastic front, lacquered RAL9003 finish and 34.5mm depth suit 40mm boxes.

Product characteristics
  • Do not disturb/make up room command push button for hotel room management applications
  • Basic element with central cover plate for installation in Altair modular frames
  • Rated for 240V operation with mandatory neutral connection for reliable command signaling
  • Matt white thermoplastic front (similar to RAL 9003), lacquered, non-transparent for discreet visual integration
  • Compact 34.5mm built-in depth, suitable for 40mm installation boxes, with terminal capacity 0.2mm² to 4mm² and clear terminal marking

Technical characteristics

Assembly arrangement Basic element with central cover plate
Model Other
Method of operation Push button
Operating principle Electronic
Number of rockers 2
Number of modules (module system) 2
Nominal voltage 240 V
With lighting No
Mounting method Module frame
Material Plastic
Material quality Thermoplastic
Surface protection Lacquered
Surface finishing Matt
Colour White
RAL-number (similar) 9003
Transparent No
Min. depth of built-in installation box 40 mm
Compatible with Apple HomeKit No
Compatible with Google Assistant No
Compatible with Amazon Alexa No
IFTTT support available No
Built-in depth 34.5 mm
Operating / setting temperature (Min-Max) -5-35 °C
Storage temperature (Min-Max) -10-70 °C
Mandatory neutral Yes
Terminal marking indication Yes
Terminals capacity (Min-Max) 0.2-4 mm²
Cable section (Min-Max) 0.2-4 mm²

Documentation

1 document
Technical Sheet
F04788EN-00.pdf pdf (0.58 Mo)
2 documents
RoHS DIRECTIVE
REACH DECLARATION
