CX3 with Netatmo Module Control
CX3 with Netatmo
Legrand
CX3 with Netatmo Module Control
REF. 412181
EAN.
3414971795600
Share
You can only compare 4 products, you must remove 1 to add this one
Technical characteristics
| Bus system KNX | No |
|---|---|
| Bus system KNX-RF (Radio Frequent) | No |
| Bus system radio frequent | Yes |
| Bus system LON | No |
| Bus system Powernet | No |
| Radio frequent bidirectional | Yes |
| Model | Multiple interface |
| Mounting method | DRA (DIN-rail adapter) |
| Width in number of modular spacings | 2.5 |
| Demounting protection | No |
| With LED indication | Yes |
| Updateable | Yes |
| Operating voltage | 240-240 V |
| Voltage type | AC |
| Protocol | TCP/IP |
| Provider dependent | No |
| Visualization | No |
| Web-Server | No |
| Radio interface | Yes |
| IR interface | No |
| Degree of protection (IP) | IP3X |
|---|---|
| Width | 45 mm |
| Height | 88.9 mm |
| Depth | 67.2 mm |
| Degree of impact strength (IK) | IK04 |
| Operating / setting temperature | -5-45 °C |
| Storage temperature | -40-70 °C |
| Supply current | 0.01-0.02 A |
| Terminal marking indication | Yes |
| Type of load | Not applicable |
| Halogen free | Yes |
| Connection type | Screwed terminal , Cable |
| Terminals capacity | 1-2.5 mm² |
| Label space/information surface | Yes |
| Fitted with USB plug | No |
| Addressable | Yes |
| Connected object | Yes |
| Application store for download | Multistore |
| Connectable by Internet box | Yes |
Documentation
4 documents
Instruction Use
Instruction Use
Technical Sheet
Technical Sheet
