This product is obsolete

Cable category 5e F/UTP 4 pairs LSZH 305 meters EU

Name: Cable category 5e F/UTP 4 pairs LSZH 305 meters EU
SKU: 033851

Legrand

REF. 033851 EAN. 3414970420282

Compare You can only compare 4 products, you must remove 1 to add this one

Conductor material	Copper
Conductor surface	Bare
Diameter conductor	0.5 mm
Nominal cross section conductor	0.2 mm²
AWG size	24
Conductor category	Class 1 = solid
Number of cores	8
Stranding element	Pairs
Core identification according to HD 308 S2	No
Core identification	Colour
Screen over stranding element	None
Screen over stranding	Foil
Approved type of underground installation	Other
Material outer sheath	Other
Specification material outer sheath	Polyethylene (PE)
Colour outer sheath	Grey
Armouring/reinforcement	None

Cable geometry	Round
Flame retardant according to IEC 60332-1-2	Yes
Halogen free according to EN IEC 60754-1	Yes
Outer diameter approximate	5.9 mm
Permitted cable outer temperature during assembling/handling (Min-Max)	0-50 °C
Permitted cable outer temperature after assembling without vibration (Min-Max)	-20-60 °C
Category	5E
NVP value	66 %
Certified for shipboard application	No
Suitable as telephone cable	Yes
Suitable as computer data cable	Yes
Weight	38 kg/km
Compatible with Grade2TV according to XP-C 90-483	No
Compatible with Grade3TV according to XP-C 90-483	No
Storage temperature (Min-Max)	-20-60 °C
RAL-number	7035

2 documents

Select all

Technical Sheet

S000099546EN-02.pdf pdf (0.09 Mo)

Technical Sheet

S000099546FR-02.pdf pdf (0.11 Mo)

1 document

Select all

Declaration of performance

DOP-O-CO/009-12220-A (0.19 Mo)
