Name: Arteor Advance - Smart in wall wireless wake up / sleep switch battery powered matt titanium - Zigbee connected
SKU: AC5703MT

Arteor Advance - Smart in wall wireless wake up / sleep switch battery powered matt titanium - Zigbee connected

REF. AC5703MT EAN. 3414972710961

With the Wake Up/Sleep in-wall wireless switch, control lights, roller shutters, or electrical appliances via customizable scenarios with a single press. Battery-powered Zigbee connectivity, app programming, and voice assistant support

Compare You can only compare 4 products, you must remove 1 to add this one

Description

Product characteristics

Wake Up/Sleep scenarios can be customized from the Home + Control app, enabling centralized control of lighting and other loads via the connected Zigbee ecosystem
LED indicator with low battery warning ensures reliable status feedback for the in-wall wireless radio transmitter
Supplied with a replaceable CR2032 lithium battery (included) offering up to 8 years of service life and 0mA standby consumption
Flush-mounted, battery-powered in-wall radio transmitter (22.5x45x43mm, built-in depth 35mm) in matt titanium finish for discreet integration in Arteor Advance installations
2-command Zigbee radio transmitter (2400MHz, 128-bit rolling code, range up to 185m, IP21, IK02, -5° C to 35° C) for smart lighting management with voice control via Amazon Alexa, Google Assistant, and Apple Siri

Recommendation / Restriction

To add your Sleep/Wake Up wireless switch to your connected installation, you first need to purchase and install a Arteor with Netatmo connected starter pack, as well as one or more Arteor with Netatmo connected switches, power outlets or lighting micromodules

The product's benefits

Installation

The Sleep/Wake Up wireless switch can also be screwed onto a flush-mounting box

Usage

Install the Sleep/Wake Up in wall wireless switch next to your bed, and launch the Sleep scenario which you will have customised to switch off the lights and lower the roller shutters

Technical characteristics

Radio frequency	2400 MHz
Rolling code system	Yes
Code length (Bit)	128
Range	185 m
Number of commands	2
With manual radio transmitter	Yes
Flush-mounted radio transmitter	Yes
Surface mounted radio transmitter	No
With radio coding device	Yes
Degree of protection (IP)	IP21
Keyboard protection cover	No
Current supply	Battery
Width	22.5 mm
Height	45 mm
Depth	43 mm
Built-in depth	35 mm
degree of impact strength (IK)	IK02
Operating / setting temperature (Min-Max)	-5-35 °C
Storage temperature (Min-Max)	0-45 °C
Standby consumption	0 mA
Mandatory neutral	No
Stress test conformity (1000V)	No
Colour	Titanium

Halogen free	Yes
Antimicrobial treatment	No
Mounting method	Flush-mounted
Contains Batteries	Yes
Number of batteries (Type 1)	1
IEC code (Type 1)	CR2032
Battery ou Accumulator (Type 1)	Battery (not rechargeable)
Battery Composition (Type 1)	Lithium (battery or accumulator)
Battery Location (Type 1)	Product includes a battery
Regulation Type (Type 1)	P : Portable (Standard format)
Connected object	Yes
Operating method	Zigbee
Application store for download	App Store , Google Play Store
With voice command	Yes
Programmable	Yes
Interoperable connection Protocol	Yes
Connectable by Internet box	Yes
Compatible voice assistants	Google Assistant , Amazon Alexa , Apple Siri
Product use function	Lighting management
Application name	Home + Control
Programming way	Smartphone apps
Battery weight (g) for Type 1	3 g
Number of Single Element (Pack1)	1
