Arteor Advance - Rfid keycard switch BUS 2 modules matt white Altair - BUS/SCS hotel room energy control - LED backlit slot

Arteor Advance Legrand

Arteor Advance - Rfid keycard switch BUS 2 modules matt white Altair - BUS/SCS hotel room energy control - LED backlit slot

REF. AC5222MW EAN. 3414972794923
Rfid keycard switch BUS/SCS - 2 modules - Matt white offers 13.56MHz keycard recognition and addressable SCS operation. Its LED backlit slot ensures easy location, while configurable switch-off delay optimizes hotel room energy management.
Download product sheet
You can only compare 4 products, you must remove 1 to add this one

Description

Rfid keycard switch BUS/SCS - 2 modules - Matt white offers 13.56MHz keycard recognition and addressable SCS operation. Its LED backlit slot ensures easy location, while configurable switch-off delay optimizes hotel room energy management.

Product characteristics
  • Accepts ISO keycards with sizes between 45mm and 54mm, ensuring compatibility with standard hotel access cards
  • BUS/SCS operating method for integration into Legrand hotel management and room automation bus systems
  • 2-module matt white Altair front, suitable for modular installation in Arteor Advance frames
  • 13.56MHz rfid keycard recognition for secure, contactless room power control
  • LED backlit card slot for easy location in the dark and configurable automatic switch-off delay for energy saving in hotel guest rooms
Recommendation / Restriction
  • Hotel guest rooms - Indoor usage only

The product's benefits

Avantages
  • Thanks to the LED backlit slot, the device can be found in the dark
  • An automatic switch off delay can also be set

Technical characteristics

Bus system KNX No
Bus system KNX-RF (Radio Frequency) No
Bus system radio frequency No
Bus system LON No
Bus system Powernet No
Other bus systems Other
Radio frequency bidirectional No
Mounting method Module frame
With anti-theft/dismantling protection No
With bus connection Yes
Number of actuation points 1
Number of buttons 1
With LED indication Yes
With label area No
With display No
Material Plastic
Material quality Thermoplastic
Transparent No
With room temperature controller No
With IR sensor No
Degree of protection (IP) Other
degree of impact strength (IK) Other
Operating / setting temperature (Min-Max) -5-35 °C
Storage temperature (Min-Max) -10-70 °C
Frequency (Min-Max) 0-0 Hz
Standby consumption 5 mA
Terminal marking indication No
Halogen free No
Antimicrobial treatment No
Terminals capacity (Min-Max) 0.34-2.5 mm²
Cable nature for connection Flexible or rigid
Addressable Yes
Contains Batteries No
Connected object No
Operating method SCS
Programming way Configurator
Programmable Yes

Documentation

2 documents
Instruction Use
LE15321AA.pdf pdf (1.08 Mo)
Technical Sheet
F04789EN-00.pdf pdf (0.46 Mo)
