Arteor Advance - DO NOT disturb/make UP room push button with LED 12V corridor control matt white - 12V DC modular push button

Arteor Advance Legrand

Arteor Advance - DO NOT disturb/make UP room push button with LED 12V corridor control matt white - 12V DC modular push button

REF. AC27103MW EAN. 3414973149333
Allows guests to signal room status with "Do Not Disturb" or "Make Up Room" via a 12V electronic push button. Integrated red/green LEDs provide clear corridor indication. Screw terminals and 2-module matt white design ensure easy install
Download product sheet
You can only compare 4 products, you must remove 1 to add this one

Description

Allows guests to signal room status with "Do Not Disturb" or "Make Up Room" via a 12V electronic push button. Integrated red/green LEDs provide clear corridor indication. Screw terminals and 2-module matt white design ensure easy install

Product characteristics
  • 12V DC electronic push button module for corridor DND/MUR signaling in low-voltage hotel room control systems
  • Matt white plastic front with powdery smooth matt finish (similar to RAL 9003) for discreet integration in Arteor Advance installations
  • Supplied with integrated LED light sources providing clear status indication and easy location in low ambient light
  • Single bell push button with bell symbol plus two 12V LEDs (red for Do Not Disturb, green for Make Up Room) for intuitive guest feedback
  • 2-module, screw-mounted device with screwed terminals (1 to 4mm² flexible or rigid), IP20/IK04 rating, and 45x45x40.2mm dimensions for standard indoor modular frames
Recommendation / Restriction
  • Recommended for inside use only

The product's benefits

Installation
  • Has screw-type terminals for easy and secure wire installation.
Usage
  • The switch is rated for up to 40,000 operation cycles, exceeding the standard requirements for exceptional durability.
Avantages
  • Subtle touch & sound
  • Powdery white with a smooth matt aspect
  • The square format enables modularity

Technical characteristics

Assembly arrangement Modular device for domestic switching devices
Model Single push button
Method of operation Push button
Operating principle Electronic
Number of contacts as normally closed contact 0
Number of contacts as normally open contact 1
Number of contacts as change-over contact 0
Number of revolving contacts 0
Contactless type Yes
Number of rockers 1
Number of modules (module system) 2
Nominal voltage 12 V
With lighting Yes
With light source Yes
With complemantary luminous signal No
Monitoring contact No
Connection type Screwed terminal
Mounting method Module frame
Type of fastening Screw mounting
Material Plastic
Material quality Thermoplastic
Halogen free No
Antimicrobial treatment No
Surface protection Untreated
Surface finishing Matt
Colour White
RAL-number (similar) 9003
Transparent No
Label space/information surface Yes
Imprint Symbol "bell"
Suitable for degree of protection (IP) IP20
degree of impact strength (IK) IK04
Device width 45 mm
Device height 45 mm
Device depth 40.2 mm
Min. depth of built-in installation box 35 mm
Compatible with Apple HomeKit No
Compatible with Google Assistant No
Compatible with Amazon Alexa No
IFTTT support available No
Built-in depth 31.7 mm
Operating / setting temperature (Min-Max) -5-35 °C
Storage temperature (Min-Max) -10-70 °C
Voltage type DC
Mandatory neutral No
Terminal marking indication Yes
Terminals capacity (Min-Max) 1-4 mm²
Cable nature for connection Flexible or rigid
Cable section (Min-Max) 1-4 mm²
