Arteor Advance - Arteor smart rotary dimmer 2 module matt black - 230V 7-200W LED dimming - Zigbee, app and voice control

Arteor Advance Legrand

Arteor Advance - Arteor smart rotary dimmer 2 module matt black - 230V 7-200W LED dimming - Zigbee, app and voice control

REF. AC52109MB EAN. 3414972713368
The Rotary Dimmer allows you to adjust light intensity and manage lighting up to 200W. It offers remote control via the Home + Control app or voice through Amazon Alexa, Apple Siri, or Google Assistant.
Download product sheet
You can only compare 4 products, you must remove 1 to add this one

Description

The Rotary Dimmer allows you to adjust light intensity and manage lighting up to 200W. It offers remote control via the Home + Control app or voice through Amazon Alexa, Apple Siri, or Google Assistant.

Product characteristics
  • On/off switching and rotary dimming for precise lighting management
  • Controls universal and LED retrofit loads from 7W to 200W at 230V, 50-60Hz
  • Configurable locator and indicator light functions for easier device identification in the dark
  • Auxiliary input for additional pushbuttons, enabling multi-point control of the same lighting circuit
  • Wiring possible without neutral (neutral recommended) for extended compatibility with various lighting types and existing installations
Recommendation / Restriction
  • It requires to have previously installed a smart gateway "with Netatmo".

The product's benefits

Installation
  • Can replace a traditional switch, in a standard 40mm depth flush-mounting box
Usage
  • Remote lighting control using the Home + Control app or voice
Avantages
  • Perfect integration with the aesthetics of other appliance controls
  • Ergonomics and bright design designed for a perfect grip of the product

Technical characteristics

Assembly arrangement Basic element with central cover plate
Model Tronic
Type of load Universal and LED Retrofit
Substation input Yes
Light value memory No
Applicable with button Yes
Applicable with movement sensor Yes
Applicable with presence indicator No
Applicable with time switch/timer Yes
Applicable with transmission button Yes
Applicable with infrared button No
Mounting method Flush-mounted
Material Plastic
Material quality Thermoplastic
Surface protection Lacquered
Surface finishing Matt
Colour Black
Transparent No
Nominal voltage 230 V
Frequency (Min-Max) 50-60 Hz
Switch capacity (Min-Max) 7-200 W
Number of channels 1
Type of fastening Clamp mounting
Min. depth of built-in installation box 35 mm
Compatible with Apple HomeKit Yes
Compatible with Google Assistant Yes
Compatible with Amazon Alexa Yes
IFTTT support available No
Width 45 mm
Height 45 mm
Depth 56.2 mm
Built-in depth 33 mm
degree of impact strength (IK) IK04
Degree of protection (IP) IP20
Operating / setting temperature (Min-Max) -5-35 °C
Storage temperature (Min-Max) 0-45 °C
Standby consumption 1.2 mA
Mandatory neutral No
Terminal marking indication Yes
Stress test conformity (1000V) No
Halogen free Yes
Antimicrobial treatment No
Connection type Screwed terminal
Number of terminals 4
Terminals capacity (Min-Max) 1.5-2.5 mm²
Cable section (Min-Max) 1.5-2.5 mm²
Label space/information surface No
Contains Batteries No
Connected object Yes
Operating method Zigbee
Application store for download App Store , Google Play Store
With voice command Yes
Programmable Yes
Interoperable connection Protocol Yes
Connectable by Internet box Yes
Compatible voice assistants Google Assistant , Amazon Alexa , Apple Siri
Product use function Lighting management
Application name Home + Control
Programming way Smartphone apps

Documentation

2 documents
Instruction Use
LE15489AA.pdf pdf (3.94 Mo)
Technical Sheet
F04890EN-00.pdf pdf (0.71 Mo)
