Arteor Advance - 8 modules plate+frame matt black - 8-module horizontal cover frame - Matt deep black thermoplastic - Minimalist design

Arteor Advance Legrand

Arteor Advance - 8 modules plate+frame matt black - 8-module horizontal cover frame - Matt deep black thermoplastic - Minimalist design

REF. AC1206MB EAN. 3414972738736
This 8 modules plate+frame matt black offers eight-module capacity in a minimalist square format for flexible configuration. Its matt black thermoplastic construction ensures long-term aesthetics against daily wear and sunlight.
Download product sheet
Finition :
Number of modules horizontal (module system) :
Number of modules vertical (module system) :
You can only compare 4 products, you must remove 1 to add this one

Description

This 8 modules plate+frame matt black offers eight-module capacity in a minimalist square format for flexible configuration. Its matt black thermoplastic construction ensures long-term aesthetics against daily wear and sunlight.

Product characteristics
  • Eight-module horizontal cover frame enabling high-density configuration in a single 8M row (8 modules horizontal, 1 module vertical).
  • Deep matt black finish for a minimalist, contemporary aesthetic that coordinates with modern devices and decor.
  • Plate and frame manufactured from thermoplastic polycarbonate, halogen free, providing robust mechanical strength and improved fire performance.
  • Square-format design with snap-on fastening for precise alignment and modular flexibility within the Arteor Advance range.
  • Flush-mounted plastic frame with IK02 impact resistance and operating temperature from -5 to 35° C, ensuring reliable indoor performance and long-term visual stability.
Recommendation / Restriction
  • Recommended for inside use only

The product's benefits

Installation
  • The plate contains an adjuster that ensures perfect installation on the wall
Usage
  • Ensures long-term aesthetic against daily wear and sunlight exposure.
Avantages
  • Deep black with a smooth matte finish
  • Minimalist design
  • Square format allows modularity and flexible configuration

Technical characteristics

Number of units 1
Mounting direction Horizontal
Number of units horizontal 1
Number of units vertical 1
Number of modules horizontal (module system) 8
Number of modules vertical (module system) 1
With mounting grid Yes
Flush-mounted installation Yes
Suitable for subfloor installation duct box No
Suitable for wall duct No
Label space/information surface No
Material Plastic
Material quality Thermoplastic
Halogen free Yes
Antimicrobial treatment No
Surface protection Untreated
Surface finishing Matt
Colour Black
Transparent No
With hinged lid No
degree of impact strength (IK) IK02
Type of fastening Engage (snap)
Width 252.5 mm
Height 90 mm
Depth 8.5 mm
Operating / setting temperature (Min-Max) -5-35 °C
Storage temperature (Min-Max) -10-70 °C
Latin wood species Not applicable
Certification of wood (list) Not applicable
Wood Climate area Not applicable
