Arteor Advance - 2x6M BS plate+frame rose - 2x6 module square cover frame - Matt thermoplastic, halogen free - Pink blush

Arteor Advance Legrand

Arteor Advance - 2x6M BS plate+frame rose - 2x6 module square cover frame - Matt thermoplastic, halogen free - Pink blush

REF. AC1209RS EAN. 3414972922074
This 2x6 modules Arteor Advance cover frame delivers precise flush-mounted alignment and modular flexibility. Its halogen-free thermoplastic construction with lacquered matt pink finish offers IK02 impact resistance.
Download product sheet
Finition :
Number of modules horizontal (module system) :
Number of modules vertical (module system) :
You can only compare 4 products, you must remove 1 to add this one

Description

This 2x6 modules Arteor Advance cover frame delivers precise flush-mounted alignment and modular flexibility. Its halogen-free thermoplastic construction with lacquered matt pink finish offers IK02 impact resistance.

Product characteristics
  • 2x6-module BS cover frame enabling high-density horizontal configurations for domestic switching devices
  • Rose pink finish with subtle blush effect for differentiated aesthetic integration in premium interiors
  • Plates are made of halogen-free thermoplastic polycarbonate with lacquered matt surface for enhanced durability and safety
  • Square, minimalist design allowing modularity and flexibility in a compact 237.5x178mm footprint
  • Flush-mounted snap-on frame with integrated adjuster for precise wall alignment; recommended for indoor use within -5 to 35° C operating temperature range
Recommendation / Restriction
  • Recommended for inside use only

The product's benefits

Usage
  • The plate contains an adjuster that ensures perfect installation on the wall
Avantages
  • Pink finish evoking subtle blush effect
  • Minimalist design
  • Square design allows modularity and flexibility in a compact configuration

Technical characteristics

Number of units 2
Mounting direction Horizontal
Number of units horizontal 1
Number of units vertical 2
Number of modules horizontal (module system) 6
Number of modules vertical (module system) 2
With mounting grid Yes
Flush-mounted installation Yes
Suitable for subfloor installation duct box No
Suitable for wall duct No
Label space/information surface No
Material Plastic
Material quality Thermoplastic
Halogen free Yes
Antimicrobial treatment No
Surface protection Lacquered
Surface finishing Matt
Colour Pink
Transparent No
With hinged lid No
degree of impact strength (IK) IK02
Type of fastening Engage (snap)
Width 237.5 mm
Height 178 mm
Depth 8.5 mm
Operating / setting temperature (Min-Max) -5-35 °C
Storage temperature (Min-Max) -10-70 °C
Latin wood species Not applicable
Certification of wood (list) Not applicable
Wood Climate area Not applicable
