Arteor Advance - 2x6 modules French/Schuko plate brushed stainless steel - Real brushed stainless steel frame - Horizontal

Arteor Advance Legrand

Arteor Advance - 2x6 modules French/Schuko plate brushed stainless steel - Real brushed stainless steel frame - Horizontal

REF. AC1122BS EAN. 3414973069839
This 2x6 modules French/Schuko plate in brushed stainless steel offers refined square-format design and IP20 protection. Its halogen-free metal construction and matt finish ensure long-term aesthetics.
Download product sheet
Finition :
Number of modules horizontal (module system) :
Number of modules vertical (module system) :
You can only compare 4 products, you must remove 1 to add this one

Description

This 2x6 modules French/Schuko plate in brushed stainless steel offers refined square-format design and IP20 protection. Its halogen-free metal construction and matt finish ensure long-term aesthetics.

Product characteristics
  • 2x6 modules French/Schuko cover frame for domestic switching devices, enabling high-density horizontal configurations (6 modulesx2 rows, 12 units total).
  • Brushed stainless steel metal plate with matt surface finish and IP20 rating, providing robust mechanical protection for indoor applications.
  • Plates are made of real brushed stainless steel, halogen free and non-transparent, ensuring long-term aesthetic stability against daily wear and sunlight exposure.
  • Square-format frame with engage (snap) fastening and label space, allowing modularity, flexible configuration, and precise alignment in horizontal installations.
  • Flush-mounted cover frame suitable for subfloor installation duct boxes and wall ducts, with compact dimensions (237.5x178x8.5mm) for clean, integrated wall layouts.
Recommendation / Restriction
  • Recommended for inside use only

The product's benefits

Installation
  • The plate contains an adjuster that ensures perfect installation on the wall
Usage
  • Ensures long-term aesthetic against daily wear and sunlight exposure.
Avantages
  • Real brushed stainless steel, set in a cradle, with a slight ethereal effect
  • Refined design
  • Square format allows modularity and flexible configuration

Technical characteristics

Number of units 2
Mounting direction Horizontal
Number of units horizontal 1
Number of units vertical 2
Number of modules horizontal (module system) 6
Number of modules vertical (module system) 2
With mounting grid No
Flush-mounted installation Yes
Suitable for subfloor installation duct box Yes
Suitable for wall duct Yes
Suitable for built-in installation No
Label space/information surface Yes
Material Metal
Material quality Stainless steel
Halogen free Yes
Antimicrobial treatment No
Surface protection Brushed
Surface finishing Matt
Colour Stainless steel
Transparent No
With hinged lid No
Degree of protection (IP) IP20
Type of fastening Engage (snap)
Width 237.5 mm
Height 178 mm
Depth 8.5 mm
Built-in width 135.5 mm
Built-in height 45.5 mm
Latin wood species Not applicable
Certification of wood (list) Not applicable
Wood Climate area Not applicable

Documentation

1 document
Technical Sheet
F04878EN-00.pdf pdf (0.53 Mo)
