Arteor Advance - 2 modules light dimmer 60W to 400W halogen matt white - Turn button operation - 230V to 240V AC - IP20 indoor use

Arteor Advance Legrand

Arteor Advance - 2 modules light dimmer 60W to 400W halogen matt white - Turn button operation - 230V to 240V AC - IP20 indoor use

REF. AC24103MW EAN. 3414972752534
Allows adjustment of light output for 60W to 400W halogen loads at 230V to 240V. The 2-module matt white dimmer features leading and trailing edge control with a rotary knob and screw terminals for indoor IP20 installation.
Download product sheet
Finition :
You can only compare 4 products, you must remove 1 to add this one

Description

Allows adjustment of light output for 60W to 400W halogen loads at 230V to 240V. The 2-module matt white dimmer features leading and trailing edge control with a rotary knob and screw terminals for indoor IP20 installation.

Product characteristics
  • Two-module modular dimmer for resistive halogen loads, 60-400W at 230-240V AC
  • Matt white lacquered thermoplastic finish for a discreet, modern appearance
  • Turn-button phase-cut dimmer (leading and trailing edge) for controlling dimmable halogen bulbs
  • Rated power range 60-400W resistive load with up to 500W LED switching capability
  • Compact 45x45x57mm device, suitable for installation boxes with minimum 35mm depth
Recommendation / Restriction
  • Recommended for inside use only

The product's benefits

Installation
  • Has screw-type terminals for easy and secure wire installation.
Usage
  • Rotative switch
Avantages
  • Compatibility with a wide range of "dimmable" halogen bulbs
  • Powdery white with a smooth matt aspect

Technical characteristics

Assembly arrangement Modular device for domestic switching devices
Method of operation Turn button
Number of modules (module system) 2
Number of units 1
App control via Bluetooth No
Dimming phase cut-on (leading edge) Yes
Dimming phase cut-off (trailing edge) Yes
Serial dimmer No
Type of load Resistive load
Substation input No
Light value memory No
Applicable with button No
Applicable with movement sensor No
Applicable with presence indicator No
Applicable with time switch/timer No
Applicable with transmission button No
Applicable with infrared button No
Min. brightness controllable No
Mounting method Module frame
Type of fastening Mounting with screw
Material Plastic
Material quality Thermoplastic
Halogen free No
Surface protection Lacquered
Surface finishing Matt
Colour White
Transparent No
Suitable for degree of protection (IP) IP20
Nominal voltage (Min-Max) 230-240 V
Nominal power resistive load (Min-Max) 60-400 W
Max. switching power LED 500 W
Connection type Screwed terminal
Device width 45 mm
Device height 45 mm
Device depth 57 mm
Min. depth of built-in installation box 35 mm
Compatible with Apple HomeKit No
Compatible with Google Assistant No
Compatible with Amazon Alexa No
IFTTT support available No
Voltage type AC
Mandatory neutral No
Terminal marking indication No
Antimicrobial treatment No
Cable nature for connection Flexible
