Arteor Advance - 2 modules electric floor heating thermostat dark bronze - 230V AC room control - 10° C to 30° C adjustable range-IP30

Arteor Advance Legrand

Arteor Advance - 2 modules electric floor heating thermostat dark bronze - 230V AC room control - 10° C to 30° C adjustable range-IP30

REF. AC671DB EAN. 3414972928601
Thermostat for electric floor heating offering precise 230VAC control with 1 change-over contact up to 8A, IP30 protection, and 10° C to 30° C adjustment. Its 2-module modular design with turn operation ensures robust integration.
Download product sheet
You can only compare 4 products, you must remove 1 to add this one

Description

Thermostat for electric floor heating offering precise 230VAC control with 1 change-over contact up to 8A, IP30 protection, and 10° C to 30° C adjustment. Its 2-module modular design with turn operation ensures robust integration.

Product characteristics
  • Two-module modular room thermostat for electric floor heating, 2M format for domestic switching devices
  • Dark bronze finish matching Arteor Advance aesthetic for coordinated high-end installations
  • Adjustable operating temperature range from -5° C to 35° C with measuring range from 10° C to 30° C for precise floor heating control
  • 230V AC power supply with change-over contact (NO/NC), max. Contact voltage 250V and max. Contact load 8A
  • IP30 protection degree with compact dimensions (45x45x47mm) and turn-knob operation for robust, intuitive use in indoor environments
Recommendation / Restriction
  • Recommended for inside use only

The product's benefits

Installation
  • Has screw-type terminals for easy and secure wire installation.
Usage
  • With one potential free N/O contact and LED
Avantages
  • Deep bronze finish evoking classic aesthetic

Technical characteristics

Type of power supply 230 V AC
Connection 3-/4-wire
With receiver No
Measuring range (Min-Max) 10-30 °C
External sensor No
Thermal feedback None
Control characteristic Other
Suitable for heating Yes
Number of heater outputs 1
Suitable for cooling Yes
Number of cooler outputs 1
Differential value (Min-Max) 2-2 K
Adjustable differential No
Temperature readable No
With sound indicator No
Sensor/feeler type Other
Mounting method Modular device for domestic switching devices
Number of modules (module system) 2
With display No
Operation Turn
With tap water circuit No
Contact type Change-over contact (NO/NC)
Max. contact voltage 250 V
Max. contact load 8 A
Degree of protection (IP) IP30
Explosion-proof No
Colour Bronze
Height 45 mm
Width 45 mm
Depth 47 mm
Compatible with Apple HomeKit No
Compatible with Google Assistant No
Compatible with Amazon Alexa No
IFTTT support available No
Operating / setting temperature (Min-Max) -5-35 °C
Storage temperature (Min-Max) -10-70 °C
