Arteor Advance - 2 modules all lights on/off master switch with icons matt black - 2-module two-way rocker - 230V AC 10A IP20

Arteor Advance Legrand

Arteor Advance - 2 modules all lights on/off master switch with icons matt black - 2-module two-way rocker - 230V AC 10A IP20

REF. AC22114MB EAN. 3414972748056
Allows controlling light from two locations with a 2 modules all-lights ON/OFF master switch. The matt black thermoplastic rocker ensures smooth operation. Rated 230V, 20AX with screw terminals for durable indoor IP20 lighting circuits.
Download product sheet
You can only compare 4 products, you must remove 1 to add this one

Description

Allows controlling light from two locations with a 2 modules all-lights ON/OFF master switch. The matt black thermoplastic rocker ensures smooth operation. Rated 230V, 20AX with screw terminals for durable indoor IP20 lighting circuits.

Product characteristics
  • Two-module master switch for all-lights ON/OFF control in modular lighting installations
  • Matt black thermoplastic front with lacquered finish for a deep, smooth, high-end appearance
  • Rocker/button mechanism engineered for smooth, precise actuation and reliable two-way switching
  • 20A rating for safe switching of full-load inductive and resistive SBL and LED lighting circuits
  • Screw-type terminals with 0.75mm² to 1.5mm² capacity and clear terminal marking for secure, efficient wiring
Recommendation / Restriction
  • Recommended for inside use only

The product's benefits

Installation
  • Has screw-type terminals for easy and secure wire installation.
Usage
  • The switch is rated for up to 40,000 operation cycles, exceeding the standard requirements for exceptional durability.
Avantages
  • Deep black with a smooth matt aspect
  • The square format enables modularity for lighting control

Technical characteristics

Wiring system Two-way switch
Method of operation Rocker/button
Assembly arrangement Modular device for domestic switching devices
Number of modules (module system) 2
Push button switch No
Number of rockers 1
Mounting method Module frame
Type of fastening Engage (snap)
With mounting plate No
Material Plastic
Material quality Thermoplastic
Halogen free No
Antimicrobial treatment No
Surface protection Lacquered
Surface finishing Matt
Colour Black
Colour of switch operator Black
Label space/information surface No
Lighting No
Suitable for degree of protection (IP) IP20
Nominal voltage 230 V
Rated current 10 A
Connection type Screwed terminal
Heating switch No
Washing machine switch No
Device width 45 mm
Device height 45 mm
Device depth 38 mm
Min. depth of built-in installation box 25 mm
Compatible with Apple HomeKit No
Compatible with Google Assistant No
Compatible with Amazon Alexa No
Voltage type AC
Mandatory neutral No
Terminal marking indication Yes
Terminals capacity (Min-Max) 0.75-1.5 mm²
