Arteor Advance - 2 modules 20A cable junction champagne - Flush-mounted box - Screw terminals, thermoplastic halogen free - IP20 IK04

Arteor Advance Legrand

Arteor Advance - 2 modules 20A cable junction champagne - Flush-mounted box - Screw terminals, thermoplastic halogen free - IP20 IK04

REF. AC350CH EAN. 3414972926546
The socket outlet allows a cord to be connected through a robust 2-module 20A cable junction in champagne finish. Its flush-mounted thermoplastic, halogen-free body with IP20 rating ensures reliable indoor connection.
Download product sheet
Finition :
Connection system :
You can only compare 4 products, you must remove 1 to add this one

Description

The socket outlet allows a cord to be connected through a robust 2-module 20A cable junction in champagne finish. Its flush-mounted thermoplastic, halogen-free body with IP20 rating ensures reliable indoor connection.

Product characteristics
  • Two-module 20A cable junction appliance connection box for reliable cord termination in low-voltage circuits
  • Champagne (gold) thermoplastic front for aesthetic integration with Arteor Advance finishes
  • Flush-mounted square 45x45x33mm design with 20mm built-in depth for modular wall installation
  • Screw-type terminals with screwed connection system ensure secure, durable conductor clamping
  • IP20, IK04 housing, halogen-free thermoplastic, operating temperature -5-35° C for indoor residential and commercial use
Recommendation / Restriction
  • Recommended for inside use only

The product's benefits

Installation
  • Has screw-type terminals for easy and secure wire installation.
Avantages
  • The square format enables modularity

Technical characteristics

Mounting method Flush-mounted
Clamps Other
Connection system Screwed terminal
Material Plastic
Material quality Thermoplastic
Halogen free Yes
Colour Gold
Suitable for degree of protection (IP) IP20
Device width 45 mm
Device height 45 mm
Device depth 33 mm
Built-in depth 20 mm
degree of impact strength (IK) IK04
Operating / setting temperature (Min-Max) -5-35 °C
Storage temperature (Min-Max) -10-70 °C
Antimicrobial treatment No
