Arteor Advance - 1 gang 45A cable outlet champagne - Flush-mounted appliance connection box - Screw terminals, thermoplastic

Arteor Advance Legrand

Arteor Advance - 1 gang 45A cable outlet champagne - Flush-mounted appliance connection box - Screw terminals, thermoplastic

REF. AC352CH EAN. 3414972926638
The socket outlet allows a cord to be connected with a one gang 45A cable outlet in a champagne finish. Its flush-mounted thermoplastic, halogen-free body with IP20 rating ensures reliable indoor use.
Download product sheet
Finition :
You can only compare 4 products, you must remove 1 to add this one

Description

The socket outlet allows a cord to be connected with a one gang 45A cable outlet in a champagne finish. Its flush-mounted thermoplastic, halogen-free body with IP20 rating ensures reliable indoor use.

Product characteristics
  • One-gang 45A cable outlet for high-load appliance connection in flush-mounted installations
  • Champagne (gold) thermoplastic front with warm gray, ivory-infused finish for a premium architectural aesthetic
  • Screw-type terminals with screwed connection system for secure, reliable conductor termination
  • Thermoplastic, halogen-free construction with IK04 impact resistance and IP20 rating, recommended for indoor use
  • Compact 90x90x44.2mm device with 25.2mm built-in depth, enabling modular integration within the Arteor Advance range
Recommendation / Restriction
  • Recommended for inside use only

The product's benefits

Installation
  • Has screw-type terminals for easy and secure wire installation.
Avantages
  • Warm gray finish infused with ivory hues highlights silky elegance
  • The square format enables modularity

Technical characteristics

Mounting method Flush-mounted
Clamps Other
Connection system Screwed terminal
Material Plastic
Material quality Thermoplastic
Halogen free Yes
Colour Gold
Suitable for degree of protection (IP) IP20
Device width 90 mm
Device height 90 mm
Device depth 44.2 mm
Built-in depth 25.2 mm
degree of impact strength (IK) IK04
Operating / setting temperature (Min-Max) -5-35 °C
Storage temperature (Min-Max) -10-70 °C
Antimicrobial treatment No

Documentation

1 document
Technical Sheet
F04162EN-00.pdf pdf (0.61 Mo)
