Arteor Advance - 1 gang 1 module British standard plate - Sand matt lacquered aluminum cover frame - Square minimalist flush-mounted

Arteor Advance Legrand

Arteor Advance - 1 gang 1 module British standard plate - Sand matt lacquered aluminum cover frame - Square minimalist flush-mounted

REF. AC1100SD EAN. 3414972976190
This 1 gang, 1 module British Standard plate in solid sand offers a minimalist square design for modular, flush-mounted installations. Its lacquered matt aluminum construction is halogen free and impact rated IK02.
Download product sheet
Finition :
Number of modules horizontal (module system) :
Number of modules vertical (module system) :
You can only compare 4 products, you must remove 1 to add this one

Description

This 1 gang, 1 module British Standard plate in solid sand offers a minimalist square design for modular, flush-mounted installations. Its lacquered matt aluminum construction is halogen free and impact rated IK02.

Product characteristics
  • One-gang, one-module British Standard cover frame for domestic switching devices, providing a single wiring device aperture in a compact footprint
  • Solid sand sandy-gold finish in beige tone, delivering a mineral-inspired aesthetic with the cool visual sensation of metal
  • Cover plate manufactured from lacquered matt aluminum, halogen free and non-transparent, ensuring robust, long-life performance
  • Square 90x90mm front plate geometry enabling modularity and flexible horizontal or vertical 1M configurations in flush-mounted installations
  • Snap-on fastening cover frame without mounting grid, 8.5mm depth, IK02 impact resistance, for indoor flush-mounted use from -5 to 35° C
Recommendation / Restriction
  • Recommended for inside use only

The product's benefits

Usage
  • The plate contains an adjuster that ensures perfect installation on the wall
Avantages
  • Sandy gold finish reminiscent of natural mineral elegance with cool sensation of metal
  • Minimalist design
  • Square design allows modularity and flexibility in a compact configuration

Technical characteristics

Number of units 1
Mounting direction Horizontal
Number of units horizontal 1
Number of units vertical 1
Number of modules horizontal (module system) 1
Number of modules vertical (module system) 1
With mounting grid No
Flush-mounted installation Yes
Suitable for subfloor installation duct box No
Suitable for wall duct No
Label space/information surface No
Material Metal
Material quality Aluminium
Halogen free Yes
Antimicrobial treatment No
Surface protection Lacquered
Surface finishing Matt
Colour Beige
Transparent No
With hinged lid No
degree of impact strength (IK) IK02
Type of fastening Engage (snap)
Width 90 mm
Height 90 mm
Depth 8.5 mm
Operating / setting temperature (Min-Max) -5-35 °C
Storage temperature (Min-Max) -10-70 °C
Latin wood species Not applicable
Certification of wood (list) Not applicable
Wood Climate area Not applicable

Documentation

1 document
Technical Sheet
F04496EN-00.pdf pdf (0.52 Mo)
